Robotic Systems Aluminum Wire, Multi-Stranded, High Flexibility for Dynamic Applications
What is aluminum wire?
Aluminum wire is a conductive material made of pure aluminum or aluminum alloy, which is usually used in transmission lines, electrical equipment lines, and electronic equipment lines. Aluminum wire has the characteristics of light weight, high strength, good conductivity and good corrosion resistance, so it has been widely used in industrial and civil fields.
In the field of power transmission, aluminum wire is often used in transmission lines. Its light weight, high strength and excellent conductivity make the weight of transmission equipment significantly reduced, thereby reducing the load on power transmission towers and distribution equipment. At the same time, aluminum wire also has good conductivity, which can effectively reduce the line loss of wires and improve the efficiency of power transmission.
In the field of electrical equipment, aluminum wire is usually used for internal connection wires of household appliances, motors, transformers and other equipment. Its good conductivity and light weight make electrical equipment more energy-saving and environmentally friendly, and have better electrical performance. In addition, aluminum wire can also be used to manufacture components such as capacitors and inductors, further expanding its application range.
In the field of electronic equipment, aluminum wire is usually used for connecting electronic components, welding circuit boards and other applications. Its good conductivity and good welding performance make aluminum wire an important part of electronic equipment.
However, despite the many advantages of aluminum wire, there are also some disadvantages, such as the relatively poor plasticity, strength and wear resistance of aluminum wire, and it is easy to break, so it needs to be handled carefully during use. In addition, the oxides generated by the reaction of aluminum with oxygen in the air will increase resistance and reduce conductivity, so anti-corrosion work needs to be done in practical applications.
In general, aluminum wire is an important conductive material, which is widely used in power transmission, electrical equipment and electronic equipment. Its light weight, high strength and excellent conductivity have brought great convenience to modern industry and life. With the continuous development of science and technology, the production process and quality of aluminum wire will continue to improve, making greater contributions to promoting social progress and development.
Specifications
| Al |
Zn |
Mn |
Cu |
Fe |
Si |
Ti |
| ≥99.7 |
≤0.07 |
≤0.05 |
≤0.05 |
≤0.04 |
≤0.03 |
≤0.05 |
| Molecular Weight |
26.98 |
| Appearance |
Silvery |
| Melting Point |
660.37 °C |
| Boiling Point |
2467 °C |
| Density |
2700 kg/m3 |
| Solubility in H2O |
N/A |
| Poisson's Ratio |
0.35 |
| Young's Modulus |
70 GPa |
| Vickers Hardness |
167 MPa |
| Tensile Strength |
6800 psi Coldroled 16,000 psi. |
| Thermal Conductivity |
2.37 W/cm/ K @ 298.2 K |
| Thermal Expansion |
(25 °C) 23.1 µm·m-1·K-1 |
| Electrical Resistivity |
2.6548 microhm-cm @ 0 °C |
| Electronegativity |
1.5 Paulings |
| Specific Heat |
0.215 Cal/g/ K @ 25 °C |
| Heat of Fusion |
2.55 Cal/gm mole |
| Heat of Vaporization |
67.9 K-Cal/gm at om at 765 °C |
Packing & Delivery
Packing: 1 ton big bag, 20-25mt in 20' container
