1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces

I'm Online Chat Now

1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces

1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces
1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces
1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces 1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces 1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces 1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces 1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces

Large Image :  1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces

Product Details:
Place of Origin: China
Brand Name: ZHENAN
Certification: ISO9001
Model Number: RP/HP/UHP Graphite Electrodes
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1MT big bag or as per customer request
Delivery Time: 5-10 work days after received the payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000MT/per Month

1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces

Description
Grade: UHP (Ultra High Power), HP (High Power), RP (Regular Power), UHP, RP Thermal Expansion: 1.5, 1.1-1.4, ≤2.8, 2.3-2.1, 1.5 - 2.8 X10-6 / (100-600 )
Apparent Density (g/cm³ ): 1.58 - 1.76 G/cc, 1.6-1.9, 1.68-1.75g/cm3, 1.58-1.75, 1.55-1.69 G/cc Resistance (μω.m): 5.5, 4 - 9 Micro Ohm.m, 4.8-5.8μΩm, 5.5-6.5 Ohm, 6.0-9.5
Length: 1600~2400mm, 1500mm-2700mm, 250 - 2400mm, 2700, 1800-2700 Type: Electrode Block, Electrode Powder, Electrode Bolt, Graphite Electrode With Nipples, Generator
Highlight:

Electric Arc Furnaces Graphite Electrodes

,

Steel Making Graphite Electrodes

,

1600mm Graphite Electrodes

Graphite Electrodes used for Steel-Making in Electric arc furnaces

What we offer

1) Good quality control
2) Highly competitive prices
3) state-of-art technology products
4) Best professional team of lifestyle consumer electronics.
5) Smooth communication
6) Effective OEM&ODM service



How to verify the performance and power of ultra-high power graphite electrodes?

Graphite electrode is a key raw material used in industrial production. It can stably conduct electricity and heat at high temperature and high pressure. Therefore, it is widely used in important equipment such as electric furnaces and electrolytic cells. With the development of industrial technology, the requirements for graphite electrodes are getting higher and higher. Among them, ultra-high power graphite electrodes are gradually replacing traditional graphite electrodes and becoming the main product in thermoelectric equipment due to their better electrical and thermal conductivity.

The performance and power of ultra-high power graphite electrodes are very important indicators, which directly affect the stable operation and production efficiency of production equipment. Therefore, when purchasing and applying ultra-high power graphite electrodes, their performance and power need to be verified.

1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces 01600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces 1



Graphite Electrode Current Carrying Capacity




Nomina diameter RP HP UHP
Current Carrying Capacity Current Density Current Carrying Capacity Current Density Current Carrying Capacity Current Density
in mm A A/cm2 A A/cm2 A A/cm2
12 300 10000-13000 14-18 13000-17400 17-24 15000-22000 20-30
14 350 13500-18000 14-18 17400-24000 17-24 20000-30000 20-30
16 400 18000-23500 14-18 21000-31000 16-24 25000-40000 19-30
18 450 22000-27000 13-17 25000-40000 15-24 32000-45000 19-27
20 500 25000-32000 13-16 30000-48000 15-24 38000-55000 18-27
22 550 32000-40000 13-16 35000-55000 14-22 42000-64000 17-26
24 600 35000-41000 13-15 41000-61000 14-21 50000-73000 17-25
28 700 39000-48000 10-12 55000-82000 14-21 67000-99000 17-25
32 800 43000-54000 8-10 / / / /

Packing & Delivery


REMARK: the above data is just on standard of YB/T, the actual product is big different from the above. For the actual, be free to contact us, please.
Service: We can supply you with free samples, a booklet, a laboratory test report, an Industry Report, etc.
Welcome to our factory and company for a visit!


1600mm Graphite Electrodes For Steel Making In Electric Arc Furnaces 2
Company profile


ZhenAn International Co., Limited. is located in Anyang City, Henan Province, the hometown of Oracle. The company specializes in the research and development, production and sales, and international trade of graphite electrodes and carbon products. It has nearly 30 years of experience in graphite electrode production and research and development and independent intellectual property rights. It is a domestic professional production and research and development enterprise with excellent quality, complete varieties and multiple specifications. Its products enjoy a high reputation at home and abroad.


FAQ


Q: Are you a manufacturer or a trading company?
A: We are a manufacturer with our own factory, with an annual output of 550,000 tons of various refractory materials. We not only provide high quality products with the best price, but also the best pre-sale and after-sale service.



Q: What kind of products can you provide?
A: We can supply all kinds of refractory products, such as: refractory bricks, high alumina bricks, clay bricks, magnesium-carbon bricks, silicon carbide bricks, castables, graphite products, ceramic fiber products and so on.



Q: What are your main products?
A: Our company mainly produces graphite related products. We can provide customization according to the specific needs of customers.



Q: Are you a factory or trading company?
A: We’re factory and has the independent right of export and import.
