100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace

I'm Online Chat Now

100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace

100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace
100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace
100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace 100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace 100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace 100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace 100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace

Large Image :  100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace

Product Details:
Place of Origin: China
Brand Name: ZHENAN
Certification: ISO9001
Model Number: RP/HP/UHP Graphite Electrodes
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1MT big bag or as per customer request
Delivery Time: 5-10 work days after received the payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000MT/per Month

100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace

Description
Grade: UHP (Ultra High Power), HP (High Power), RP (Regular Power), UHP, RP Thermal Expansion: 1.5, 1.1-1.4, ≤2.8, 2.3-2.1, 1.5 - 2.8 X10-6 / (100-600 )
Apparent Density (g/cm³ ): 1.58 - 1.76 G/cc, 1.6-1.9, 1.68-1.75g/cm3, 1.58-1.75, 1.55-1.69 G/cc Resistance (μω.m): 5.5, 4 - 9 Micro Ohm.m, 4.8-5.8μΩm, 5.5-6.5 Ohm, 6.0-9.5
Length: 1600~2400mm, 1500mm-2700mm, 250 - 2400mm, 2700, 1800-2700 Type: Electrode Block, Electrode Powder, Electrode Bolt, Graphite Electrode With Nipples, Generator
Highlight:

100-750mm Graphite Electrode

,

Corrosion Resistance Graphite Electrode

,

Eaf Lf Furnace Graphite Electrode

100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace

Our Services

1. We provide the best suitable products and solutions according to customer 's requirements.
2. We provide test report of the whole production process.
3. We provide safe, fast, preferential price transport scheme for customer.
4. We provide 24 hours after-sale service no matter when you contact us.





In addition, as people's awareness of environmental protection increases, the demand for renewable energy is also growing. The use of renewable energy such as solar energy and wind energy is of great significance for reducing emissions and energy consumption. As a key material for the production and storage of these energy sources, graphite electrodes will also play an important role in the future renewable energy field. The application of ultra-high power graphite electrodes will provide more possibilities for the development of renewable energy, and the prospect of becoming a mainstream material is more optimistic.

In general, ultra-high power graphite electrodes are expected to become mainstream materials in the future. It has excellent electrical conductivity, thermal conductivity and heat resistance, which can meet the growing industrial needs. In traditional metal smelting, chemical industry, new energy vehicles and renewable energy fields, ultra-high power graphite electrodes have broad application prospects. With the continuous advancement of technology and the continuous growth of demand, ultra-high power graphite electrodes are expected to replace traditional graphite electrodes and become the mainstream graphite electrode material in the future.

100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace 0100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace 1



Graphite Electrode Current Carrying Capacity




Nomina diameter RP HP UHP
Current Carrying Capacity Current Density Current Carrying Capacity Current Density Current Carrying Capacity Current Density
in mm A A/cm2 A A/cm2 A A/cm2
12 300 10000-13000 14-18 13000-17400 17-24 15000-22000 20-30
14 350 13500-18000 14-18 17400-24000 17-24 20000-30000 20-30
16 400 18000-23500 14-18 21000-31000 16-24 25000-40000 19-30
18 450 22000-27000 13-17 25000-40000 15-24 32000-45000 19-27
20 500 25000-32000 13-16 30000-48000 15-24 38000-55000 18-27
22 550 32000-40000 13-16 35000-55000 14-22 42000-64000 17-26
24 600 35000-41000 13-15 41000-61000 14-21 50000-73000 17-25
28 700 39000-48000 10-12 55000-82000 14-21 67000-99000 17-25
32 800 43000-54000 8-10 / / / /

Packing & Delivery


REMARK: the above data is just on standard of YB/T, the actual product is big different from the above. For the actual, be free to contact us, please.
Service: We can supply you with free samples, a booklet, a laboratory test report, an Industry Report, etc.
Welcome to our factory and company for a visit!


100-750mm UHP HP RP Graphite Electrode Corrosion Resistance for Eaf Lf Furnace 2
Company profile


ZhenAn International Co., Limited. is located in Anyang City, Henan Province, the hometown of Oracle. The company specializes in the research and development, production and sales, and international trade of graphite electrodes and carbon products. It has nearly 30 years of experience in graphite electrode production and research and development and independent intellectual property rights. It is a domestic professional production and research and development enterprise with excellent quality, complete varieties and multiple specifications. Its products enjoy a high reputation at home and abroad.


RFQ


Q: Can I get some samples?
A: Yes, sample order is available for quality check and market test. But you have to pay the sample cost and express cost.



Q: Do you receive customized order?
A: Yes, ODM & OEM are welcomed.



Q: What's the lead time?
A: According to the order quantity, small order usually need 3-5 days, big order need negotiation.



Q: What's your payment terms?
A: We receive Escrow, T/T, West Union, Cash and etc



Q: Are you a manufacturer or a trading company?
A: We are a manufacturer with our own factory, with an annual output of 550,000 tons of various refractory materials. We not only provide high quality products with the best price, but also the best pre-sale and after-sale service.



Q: What kind of products can you provide?
A: We can supply all kinds of refractory products, such as: refractory bricks, high alumina bricks, clay bricks, magnesium-carbon bricks, silicon carbide bricks, castables, graphite products, ceramic fiber products and so on.



Q: What are your main products?
A: Our company mainly produces graphite related products. We can provide customization according to the specific needs of customers.
