Product Details:
|
Product Composition: | Silicon Carbide | Use: | Refractory, Polishing, Lapping, Blasting |
---|---|---|---|
Color: | Black,Green | Application: | Refractory, Polishing, Lapping, Blasting |
Brand Name: | ZHENAN | Material: | Sic |
Highlight: | 325 Black Silicon Carbide,F12-F220 Black Silicon Carbide,240 Black Silicon Carbide |
Description:
Why SiC wins over Si in power applications?
Despite being the most widely used semiconductor in electronics, silicon is beginning to show some limitations, especially in high-power applications.
A relevant factor in these applications is the bandgap, or energy gap, that a semiconductor offers. When the bandgap is high, the electronic devices it uses can be smaller, run faster, and be more reliable. It can also operate at higher temperatures, voltages, and frequencies than other semiconductors. Silicon has a bandgap of about 1.12eV, while silicon carbide has a bandgap value nearly three times greater at about 3.26eV.
Specifications:
Black Silicon Carbide powder Content for Concretion Grinder | ||||
Brand | Grit Size | Chemical Composition(%) | ||
SIC(min) | F.C(max) | Fe2O3(max) | ||
Black silicon carbide |
F12-F90 | 98.5 | 0.20 | 0.60 |
F100-F150 | 98.5 | 0.30 | 0.80 | |
F180-F220 | 97.0 | 0.30 | 1.20 | |
Black Silicon Carbide powder Content for Coating Grinder | ||||
Brand | Grit Size | Chemical Composition(%) | ||
SIC(min) | F.C(max) | Fe2O3(max) | ||
C-P | P12-P100 | 98.0 | 0.25 | 0.70 |
P120-P150 | 97.5 | 0.35 | 0.90 | |
P180-P220 | 96.0 | 0.35 | 1.35 |
Packing & Delivery
Packing: 1 ton big bag, 20-25mt in 20' container
FAQ:
Q : How can you control your quality?
A : For each production processing, ZhenAn have complete QC system for the chemical composition and Physical properties. After production, all the goods will be tested, and the quality certificate will be shipped along with goods.
Q: Are you a manufacture or trader?
A: Both, we not only can provide the high quality products with the best price, but also can offer the best pre-sale service and after-service.
Q : Do you provide free samples?
A : Of course, free samples are available.
Q: What is your lead time?
A : It usually needs about 15- 20 days after receiving the PO.
