Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode

I'm Online Chat Now

Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode

Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode
Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode
Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode

Large Image :  Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode

Product Details:
Place of Origin: China
Brand Name: ZHENAN
Certification: ISO9001
Model Number: RP/HP/UHP Graphite Electrodes
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1MT big bag or as per customer request
Delivery Time: 5-10 work days after received the payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000MT/per Month

Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode

Description
Grade: UHP (Ultra High Power), HP (High Power), RP (Regular Power), UHP, RP Thermal Expansion: 1.5, 1.1-1.4, ≤2.8, 2.3-2.1, 1.5 - 2.8 X10-6 / (100-600 )
Apparent Density (g/cm³ ): 1.58 - 1.76 G/cc, 1.6-1.9, 1.68-1.75g/cm3, 1.58-1.75, 1.55-1.69 G/cc Resistance (μω.m): 5.5, 4 - 9 Micro Ohm.m, 4.8-5.8μΩm, 5.5-6.5 Ohm, 6.0-9.5
Length: 1600~2400mm, 1500mm-2700mm, 250 - 2400mm, 2700, 1800-2700 Type: Electrode Block, Electrode Powder, Electrode Bolt, Graphite Electrode With Nipples, Generator
Highlight:

700mm Graphite Electrode

,

UHP Graphite Electrode

,

2700mm Graphite Electrode

Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode



What are the applications and properties of graphite electrodes?
Graphite electrodes are high-purity carbon materials mainly used in high-temperature equipment in metallurgy, chemical engineering, and power industries. They possess excellent electrical conductivity, thermal conductivity, and corrosion resistance, enabling them to withstand extreme working conditions under high temperatures and pressures.


Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode 0





UHP Graphite Electrode Specification List



UHP Size and Tolerance
Diameter Length(mm)
Nominal diameter Actual diameter Nominal length Tolerance Short feet length
mm inch max min mm mm max min
200 8 207 202







1800/2000/

2200/2300

2400/2700







±100







-100











-275





250 10 257 252
300 12 307 302
350 14 357 352
400 16 409 403
450 18 460 454
500 20 511 505
550 22 562 556
600 24 613 607
700 28 714 708



Packing & Delivery


REMARK: the above data is just on standard of YB/T, the actual product is big different from the above. For the actual, be free to contact us, please.
Service: We can supply you with free samples, a booklet, a laboratory test report, an Industry Report, etc.
Welcome to our factory and company for a visit!


Dia 75mm-700mm L1800-2700mm UHP HP RP Grade Eaf Graphite Electrode 1
Company profile


zhenAn has been in the business of ferroalloy for 30 years now. It is a leading manufacturer and supplier of ferro silicon,silicon manganese,silicon metal,silicon carbide,high carbon silicon and so on.our company is a large-sized production enterprise integrating research, development, production and sales.



Our company locates in Anyang city,Henan province of China a total area of about 15,000 square.With many years growing and developing,our company has domestic advanced smelting furnaces,crushing and screening production lines with annual output of 20000 tons.At the some time has two laboratories and a metallurgical materials testing center with dozens of senior researchers.The products are supplied to many large and medium-sized iron and steel enterprises in China, and exported to Japan, Korea, India, Europe and the United States.


FAQ


Q: Where can I get product and price information?

A: Send us inquiry e-mail, we will contact with you when we receive your email,or contact me on chat app.



Q: What is the term of the delivery?

A: FOB, CFR, CIF, etc.



Q: How to delivery the goods?

A: We deliver the goods by truck to port, or loading in container in factory.



Q: Are you trading company or factory?

A: We are direct factory and have the most advanced machine and about 200 employee in our 30000m2 workshop.





Q: What's the delivery time?

A: 2-3 weeks after got the deposit.
