Hot Rolled Tzm Molybdenum Mo Titanium Zirconium Molybdenum Alloy For Vacuum Furnace

Large Image : Hot Rolled Tzm Molybdenum Mo Titanium Zirconium Molybdenum Alloy For Vacuum Furnace

Product Details:

Place of Origin:	China
Brand Name:	ZhenAn
Certification:	ISO9001:2015
Model Number:	Molybdenum

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiable
Price:	Negotiable
Packaging Details:	1MT big bag or as per customer request
Delivery Time:	7-10 work days after received the payment
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	2000MT/per Month

Contact Now

Hot Rolled Tzm Molybdenum Mo Titanium Zirconium Molybdenum Alloy For Vacuum Furnace

Description

Color:	Silver	Density:	10.22 G/cm3
Hs Code:	81019500	Payment Term:	T/T, L/C, Etc.
Process:	Cold Rolled,hot Rolled,riveting	Technique:	Power Metallurgy
Highlight:	hot rolled tzm molybdenum , vacuum furnace tzm molybdenum

TZM Molybdenum Mo Titanium Zirconium Molybdenum Alloy For Vacuum Furnace

Titanium Zirconium Molybdenum (TZM) alloys are available in a variety of forms, including tubes, blocks, plates, sheets, screws, bolts, rods, bars, nozzles, and other shaped parts.TZM alloys are used in a wide range of industrial, military, and aerospace applications because of their excellent performance.

Depending on the processing method, Titanium, Zirconium, Molybdenum (TZM) tubes can be categorized into Deep Hole Drilled TZM Tubes, Sintered TZM Tubes, Welded TZM Tubes, TZM Coiled Tubes and Drawn TZM Tubes.

Compared to pure molybdenum, TZM alloys offer the following advantages

Better creep resistance

Higher recrystallization temperature

Better high-temperature strength

Better welding properties

TZM alloy (molybdenum zirconium-titanium alloy) and physical properties of pure molybdenum compared as follows:

Material	density /g·cm-3	Melting point /℃	Boiling point /℃
TZM alloy (Ti0.5/Zr0.1)	10.22	2617	4612
Mo	10.29	2610	5560

Mechanical Properties of TZM alloy (molybdenum zirconium-titanium alloy) (ri0.5 / Zr0.1) as follows:

Mechanical Properties	Elongation (%)	elasticity modulus GPa	Tensile strength Mpa	yield strength Mpa	fracture toughness MP·m1/2)
Value	<20	320	685	560-1150	5.8-29.6

TZM alloy (molybdenum zirconium-titanium alloy) high-temperature tensile strength and elongation:

Temperature	tensile strength(Mpa)	Elongation
RT	1140-1210	7.5-13.0
1000	700-720	5.2
1200	320-360	9.0
1300	190-210	11.5-13.5
1400	140-170	11-16

TZM alloy (molybdenum zirconium-titanium alloy) thermal performance and electrical properties:

Performance	coefficient of thermal expansion /K-1(20~100℃)	thermal conductivity W/m·K	Using maximum temperature in air ℃	ResistivityΩ·m
Value	5.3X10-6	126	400	(5.3~5.5)X10-8

Hot Rolled Tzm Molybdenum Mo Titanium Zirconium Molybdenum Alloy For Vacuum Furnace 0
