High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density

I'm Online Chat Now

High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density

High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density
High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density
High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density

Large Image :  High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density

Product Details:
Place of Origin: China
Brand Name: ZHENAN
Certification: ISO9001:2015
Model Number: Molybdenum Wire
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1MT big bag or as per customer request
Delivery Time: 7-10 work days after received the payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000MT/per Month

High Strength Edm Molybdenum Wire 0.18mm 10.3 G/Cm3 Density

Description
Color: Gray Place Of Origin: China
Product Name: Molybdenum Wire Brand Name: ZHENAN
Highlight:

High Strength edm molybdenum wire

,

edm molybdenum wire 0.18 mm

,

High Strength molybdenum wire 0.18 mm

High Strength 0.18mm Edm Molybdenum Wire



Description:



   Molybdenum is one of the most in-demand of all the refractory metals and is comparatively easy to shape into required forms like wires. Molybdenum wires are made by a process called mechanical deformation. Molybdenum wires are used in a wide range of applications for their physical properties like robustness in very high temperatures, high melting point, low vapour pressure, low thermal expansion and tensile strength.



Specifications:



Properties Metric Imperial
Density 10.3 g/cm³ 0.369 lb/in³
Melting point 2625°C 4760°F



Properties Metric Imperial
Tensile strength (annealed) 324 MPa 47000 psi
Shear strength (torsional strain rate 0.25/s) 500 MPa 72500 psi
Compressive yield strength (0.01% yield) 400 MPa 58000 psi
Modulus of elasticity 330 GPa 47900 ksi
Modulus of elasticity at elevated temperature (@2000°C/3630°F) 160 GPa 23200 ksi
Electrical Conductivity: 34% I.A.C.S.
Thermal Conductivity: 1.38 W/cm/K @ 298.2 K



Appearance:



Mo-wire is regular black covered with graphite. After graphite is removed it is metallic luster.



Benefits

  • Excellent Strength & Stiffness at high temperatures.
  • High purity and excellent creep resistance.
  • Good machinability and easily fabricated.
  • High dimensional stability and excellent corrosion resistance
  • Low emissivity and vapor pressure.
  • Good electrical conductivity and low thermal expansion
  • Ductile and corrosion resistant.
  • Excellent Thermal conductivity.



Application:





For wire cutting machine

For producing electric light source parts and electric vaccum components

For producing heating elements and refractory parts in high temperature furnaces

For spraying wear and tear parts of automobile and other machine to enhance their wearability





FAQ:



   Q: Are you a trading company or a manufacturer?
    A: we are a manufacturer located in Anyang City, Henan Province,China.



   Q: What's the payment term?
    A: We accept T/T, D/P, L/C.
